T Series - Temperature Sensing NTC Thermistors

The T series thermistor is small than the A series thermistor. Its rapid response time and high reliability make it suitable for use in medical equipment and thermometers.

Features

項目符號 High Accuracy
項目符號 Operating Range
項目符號 Excellent thermal cycle endurance
項目符號 Small size
項目符號 Lead Free
項目符號 Top Quality
項目符號 High Stability
項目符號 Fast Thermal Response
項目符號 Low Cost and Long Life
項目符號 RoHS compliance

Specifications

項目符號 Operating temperature range: -50oC to 110oC
項目符號 Tolerance: + 1%,  +3 or  +5%
項目符號 Dissipation constant: 0.7 mW/oC
項目符號 Thermal time constant: Typically 3.2 seconds in air
項目符號 Maximum power rating: 3.5 mW (at 25oC)

Options

項目符號

Resistance at 25oC

004K: 4K ohms 010K: 10K ohms
020K: 20K ohms 030K: 30K ohms
040K: 40K ohms 050K: 50K ohms
100K: 100K ohms 232K: 232K ohms
項目符號 Tolerance @25oC
01: +1% 03: +3%
05: +5% 　
項目符號 B value 25oC / 85oC
3100K - 4274K

　

Products of T Series
Part No. Resistance at 25oC Tolerance B Value (25oC / 85oC)
T010K013977 10K ohms +1% 3977
T050K014055 50K ohms +1% 4055
T050K013977 50K ohms +1% 3977
T100K034262 100K ohms +3% 4262
T220K034270 220K ohms +3% 4270

　
